The WA-2A is a high-voltage, Class-A opto-compressor, utilizing large-core CineMag USA Transformers, four premium vacuum tubes, and the legendary Kenetek opto-cell - considered by many to be the world’s finest.

The WA-2A operates on four tubes: two 12AX7’s, one 12BH7, and one 6aq5 (or 6P1J). We proudly use Tung-Sol and Electro-Harmonix brand tubes in the signal path, which sound very 'open' and LARGE. All 4 tubes are socketed for easy swapping and replacement.



  • '2A STYLE, TRANSFORMER BALANCED, HIGH VOLTAGE, OPTO TUBE COMPRESSOR​.

  • UTILIZES PREMIUM GRADE INPUT AND OUTPUT CINEMAG USA TRANSFORMERS.

  • USA MADE KENETEK OPTO-CELL ATTENUATOR T4' STYLE MODULE. SOCKETED TO ALLOW RETRO-FITTING WITH OTHER OPTO-CELLS.

  • PREMIUM TUNG-SOL AND ELECTRO-HARMONIX TUBES. 2X 12AX7, 1X 12BH7, 1X 6AQ5 OR 6P1.

  • FULLY DISCRETE SIGNAL PATH.

  • VARIABLE PRE-EMPHASIS, ALLOWS FOR COMPRESSION HIPASS FILTERING (TONE CONTROL).

  • STEREO-LINK CAPABLE VIA TRS CONNECTOR.

  • INPUT IMPEDANCE - 600 OHMS, BRIDGES-T CONTROL (FLOATING).

  • XLR AND TRS BALANCED LINE LEVEL OUTPUTS - 600 OHMS IMPEDANCE.
  • XLR AND TRS BALANCED LINE LEVEL INPUTS - 600 OHMS IMPEDANCE.

  • FREQUENCY RESPONSE +/- 1 DB, 15 HZ TO 20KHZ.

  • GAIN 40 DB ±1DB.

  • INPUT LEVEL +16 DB MAXIMUM.

  • OUTPUT LEVEL +10 DB NOMINAL, +16 DB MAXIMUM.

  • DISTORTION LESS THAN 0.1% THD AT ±10 DBM.

  • NOISE = -74DB.

  • ATTACK TIME - 10 MILLISECONDS.

  • RELEASE TIME - 0.06 SECONDS FOR 50% RELEASE - 0.5 TO 5 SECONDS FOR COMPLETE RELEASE.

  • METER DISPLAYS BOTH DB GAIN REDUCTION AND DB OUTPUT.

  • POWER - 115/230 VOLTS (SWITCHABLE), 50/60 HZ.

  • DIMENSIONS - 19" RACKMOUNT CHASSIS, 2U. 19" X 7" X 3.5".
